DEAN Wet BenchMajor subsystems:
Water Chiller: Used to chill one or more chemistry tanks.
Load stations: Operators place baskets of parts to be processed on a table
Hoods: Three chemical vapor hoods house several chemistry and rinse tanks.
Spin: The baskets are spun to remove most of the water that remains after the final rinse.
Unload stations: The machine places the processed baskets on a table for operators to retrieve.
Gantry: Several carriages, mounted above the hoods transport baskets through the system.
